Permalloy 80 Sheet
Permalloy 80 sheet is a high-permeability Ni-Fe alloy engineered for low-loss magnetic shielding and precision electromagnetic components in demanding environments.
Send E-mail:info@gneestainless.com
Tel:+8615824687445
Description
Gnee Steel (Tianjin) Co., Ltd. is one of the most professional manufacturers and suppliers of permalloy 80 sheet in China. With abundant experience, we warmly welcome you to wholesale customized permalloy 80 sheet from our factory. For price consultation, contact us.
What is Permalloy 80 Sheet?
Permalloy 80, also known as Ni80Fe20, is a high-nickel soft magnetic alloy with approximately 80% nickel and 20% iron. It is characterized by high initial permeability, low coercivity, and excellent magnetic shielding properties. Gnee supplies annealed Permalloy 80 sheets with uniform grain structure and tight thickness tolerance for demanding magnetic and electromagnetic applications.
Advantages of Permalloy 80 Soft Magnetic
Permalloy 80 Sheet (UNS N14080), a high-nickel soft magnetic alloy, offers a maximum permeability of up to 200,000, enabling efficient magnetic flux conduction in low- to mid-frequency ranges. With an extremely low coercivity of 0.02–0.04 A/m, it ensures rapid response to magnetic field changes. Its high electrical resistivity (580 µΩ·mm) effectively suppresses eddy current losses, making it especially suitable for precision applications such as high-frequency transformers and magnetic sensors below 1 MHz.
After proper annealing, Permalloy 80 achieves a tensile strength of ≥100,000 psi while maintaining excellent cold workability for deep drawing and spinning processes. It can be formed into ultra-thin strips as thin as 0.01 mm or complex shielding enclosures. Magnetic properties remain stable across a wide temperature range from -40°C to 125°C, with fluctuations under 1%. With a Curie temperature of 460°C-significantly higher than ferrite materials-and resistance to salt spray corrosion, the alloy is well-suited for harsh environments in aerospace and medical equipment.
In addition, Permalloy 80 complies with RoHS environmental standards, offering a reliable, low-loss solution for advanced applications in 5G communications and new energy vehicles.
Permalloy 80 Sheet Specification
Standard Name: Permalloy 80
UNS Number: N14080
Other Names: Ni80Fe20, Soft Magnetic Alloy, High-Permeability Nickel Iron Alloy
Chemical Composition (% by weight)
| Element | Content (%) |
|---|---|
| Nickel (Ni) | 78.5 – 81.5 |
| Iron (Fe) | Balance |
| Manganese (Mn) | ≤ 0.50 |
| Silicon (Si) | ≤ 0.30 |
| Carbon (C) | ≤ 0.03 |
| Sulfur (S) | ≤ 0.02 |
| Copper (Cu) | ≤ 0.20 |
Physical Properties
| Property | Value |
|---|---|
| Density | ~8.7 g/cm³ |
| Electrical Resistivity | ~580 µΩ·mm |
| Thermal Conductivity | ~21 W/m·K |
| Coefficient of Expansion | ~13 × 10⁻⁶ /K |
| Curie Temperature | ~460 °C |
| Operating Temperature Range | -40°C to +125°C |
Magnetic Properties (Annealed Condition)
| Property | Typical Value |
|---|---|
| Initial Permeability (µi) | ≥ 50,000 |
| Maximum Permeability (µmax) | Up to 200,000 |
| Coercivity (Hc) | 0.02 – 0.04 A/m |
| Saturation Flux Density (Bs) | ~0.8 Tesla |
| Core Loss (1kHz, 0.1T) | < 20 W/kg |
Available Sizes
| Thickness (mm) | Width (mm) | Length / Form |
|---|---|---|
| 0.01 – 1.0 | Up to 600 mm | Coil / Strip / Sheet |
| Tolerance | ±0.01 mm | On request |
Why Choose Gnee Permalloy 80 Sheet?
Precision Slitting & Leveling – Sheet thickness available from 0.1 mm to 1.0 mm, tolerances up to ±0.01 mm
Surface Treatment – Bright, oil-free finish; optional insulating coating for transformer or core lamination
Low MOQ & Fast Delivery – Cut-to-size and coil options with stock-ready formats available
Material Traceability – Full chemical composition and magnetic property test reports per batch
Product Testing
Ni80Fe20 soft magnetic strip supplier
Gnee Product Shipping and Packaging
