904l Stainless Steel
We supply 904L stainless steel sheet,pipe,bar,and coil in a variety of lengths and widths and can custom cut to your exact specifications.
Send E-mail:info@gneestainless.com
Tel:+8615824687445
Description
Gnee Steel (Tianjin) Co., Ltd. is one of the most professional manufacturers and suppliers of 904l stainless steel in China. With abundant experience, we warmly welcome you to wholesale customized 904l stainless steel from our factory. For price consultation, contact us.
GNEE specializes in the professional management of materials such as stainless steel, nickel-based alloys, corrosion-resistant alloys, high-temperature alloys, and special steels. Our services include flat rolling, slitting, wire cutting, waterjet/laser/plasma/saw cutting, shearing, bending, milling, welding, forging, cold drawing, peeling, mirror finishing, wire drawing, film coating, straightening, leveling, and more.
We can customize products according to customers' actual requirements and provide tailored solutions. We also offer precision cutting services for retail sales, aiming to meet different customers' personalized needs to the greatest extent possible.
Stainless Steel 904L / 1.4539 Product forms:
pipe: ½" to 6"nb Sched 40 – 6 mtr random lengths but also supplied cut to length
bars:12mm to 250mm Dia
plates:2 to 25mm Thick – generally 3000mm x 1500mm but a range of PreCuts are also available
coils:0.02mm-6.0mm
hot and cold rolled sheet and strip
904L Equivalent grades:
904L,Al-904L,S31782,UNSN08904,S39042,F904L,NAS 255,SUS890L,1.4539,015Cr21Ni26Mo5Cu2,00Cr20Ni25Mo4.5Cu
Standard Specification:
GB/T 24186-2009,GB/T 20878-2007,ASTM A240/ASME SA-240,ASTM A276,ASTM A182/ASME SA-182,ASTM A312/ASMES A312,ASTM B625/ASME B625,ASTM B673/ASME B673,JIS G4051,JIS G4303,EN 10028/2-2009 etc.
| Product Name | 904L stainless steel |
| Grades | 1.4539, AISI 904L, UNS N08904 |
| Hardness | 70-90HRB |
| Forms | Coils/Pipes/Bars/Plates/Sheets |
| Edge | Slit/Mill |
| Quantity Tolerance | ±10% |
| Paper Core Internal Diameter | Ø500mm paper core, special internal diameter core and without paper core on customer request |
| Surface Finish | NO.1/2B/2D/BA/HL/Brushed/6K/8K Mirror,etc |
| Packaging | Wooden Pallet/Wooden Case |
| Payment Terms | 30% TT deposit and 70% balance before shipment, 100% LC at sight |
| Delivery Time | 5-7 working days |
| MOQ | 200Kgs |
| Shipping Port | Shanghai/Ningbo port |
| Sample | The sample of 904L stainless steel coil is available |
904L/1.4539 Stainless Steel Mechanical properties
| Product Form | ||||||||
|---|---|---|---|---|---|---|---|---|
| C | H | P | L | L | TW/TS | |||
| Thickness (mm) Max. | 8.0 | 13.5 | 75 | 160 | 2502) | 60 | ||
| Yield Strength | Rp0.2 N/mm2 | 2403) | 2203) | 2203) | 2304) | 2305) | 2306) | |
| Rp1.0 N/mm2 | 2703) | 2603) | 2603) | 2603) | 2603) | 2503) | ||
| Tensile Strength | Rm N/mm2 | 530 - 7303) | 530 - 7303) | 520 - 7203) | 530 - 7304) | 530 - 7305) | 520 - 7206) | |
| Elongation min. in % | Jmin (Longitudinal) | - | 100 | 100 | 100 | - | 120 | |
| Jmin (Transverse) | - | 60 | 60 | - | 60 | 90 | ||
904L/1.4539 Stainless Steel Chemical Compositions
| Element | % Present (in product form) |
|---|---|
| Carbon (C) | 0.02 |
| Silicon (Si) | 0.70 |
| Manganese (Mn) | 2.00 |
| Phosphorous (P) | 0.03 |
| Sulfur (S) | 0.01 |
| Chromium (Cr) | 19.00 - 21.00 |
| Nickel (Ni) | 24.00 - 26.00 |
| Nitrogen (N) | 0.15 |
| Molybdenum (Mo) | 4.00 - 5.00 |
| Copper (Cu) | 1.20 - 2.00 |
| Iron (Fe) | Balance |
What Can We Offer?
- 904L plate:904L stainless steel plate, 904L steel plate, 904L coil, 904L flat plate, 904L strip steel, 904L cold rolled plate, 904L hot rolled plate, 904L thin plate, 904L medium plate, 904L thick plate, 904L special thick plate, etc.
- 904L bar:904L stainless steel round bar, 904L round bar, 904L disc round, 904L wire, 904L wire rod, 904L forged round, 904L round bar, 904L black bar, 904L wool round, 904L bright round, 904L polished round, 904L hot rolled round bar, 904L rolled round, 904L cold drawn round steel, etc.
- 904L pipe:904L stainless steel pipe, 904L steel pipe, 904L stainless steel seamless pipe, 904L seamless pipe, 904L stainless steel welded pipe, 904L welded pipe, 904L stainless steel precision tube, 904L precision tube, 904L capillary tube, etc.
