317 stainless steel pipe is a grade of stainless steel produced according to the American ASTM standard. It is equivalent to my country's 0Cr19Ni13Mo3 stainless steel pipe. 317 contains 19% chromium, 13% nickel and 3% molybdenum.

Have questions? GNEE sales representatives are available for live chat now

Send E-mail:info@gneestainless.com

Tel:+8615824687445

Send Inquiry Chat Now

Description

Gnee Steel (Tianjin) Co., Ltd. is one of the most professional manufacturers and suppliers of 317 stainless steel seamless pipe in China. With abundant experience, we warmly welcome you to wholesale customized 317 stainless steel seamless pipe from our factory. For price consultation, contact us.

317 stainless steel seamless pipes are produced according to the American ASTM standard, corresponding to China's 0Cr19Ni13Mo3 stainless steel pipes, and are austenitic stainless steel.
SUS 317L Pipes Tubing has excellent corrosion resistance due to its high chromium, nickel, and molybdenum content. Chromium forms a film to prevent corrosion, nickel resists stress corrosion, and molybdenum copes with chloride environments. It performs well in media such as seawater and sulfuric acid.
SUS 317 Steel Hydraulic Tubing can work stably at high temperatures of 870°C, without degrading its structure and performance, and is suitable for scenes such as high-temperature furnaces. It also has high mechanical strength, good yield and tensile strength, and both ductility and toughness. It can withstand high pressure and complex stresses to ensure a stable structure.

317 Stainless Steel Bright Annealed Pipe

Stainless Steel 317/317L PipesSpecification

Standard ASTM A/ASME SA213/A249/A269/A312/A358 CL. I to V ASTM A789/A790

Dimensions ASTM, ASME and API

Range 1/2" NB TO 24" NB IN SCH 5, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160 & XXS as Per NACE MR 01 75

Thickness 0.3mm – 50 mm

Outer Diameter 6.00 mm OD up to 914.4 mm OD

Schedule SCH 10, SCH20, SCH30, SCH40, STD, SCH60, XS, SCH80, SCH120, SCH140, SCH160, XXS

Grade specifications for 317L Stainless Steel pipe

STANDARD	UNS	WERKSTOFF NR.
SS 317	S31700	1.4449
SS 317L	S31703	1.4438

ASTM A312 Stainless Steel 317 Seamless Pipe Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	Fe
SS 317	0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	18.00 - 20.00	3.00 - 4.00	11.00 - 15.00	57.845 min

Stainless Steel 317 Pipes Mechanical & Physical Properties

Element	SS 317
Density	7.9 g/cm3
Melting Point	1400 °C (2550 °F)
Tensile Strength	Psi – 75000 , MPa – 515
Yield Strength (0.2%Offset)	Psi – 30000 , MPa – 205
Elongation	35 %

What is the difference between Stainless Steel 317 and 317L Pipes?

Due to its low carbon content, 317L stainless steel pipes have a low tendency to intergranular corrosion. After hot processing such as welding, its corrosion resistance, especially intergranular corrosion resistance, is better than 317. Generally, the strength of 317 stainless steel seamless pipes is slightly higher than that of 317L, but the toughness of 317L is relatively good.
