ASTM A554 TP316L welded Square Rectangular Tube

ASTM A554 TP316L welded square/rectangular tubing is a specialized type of stainless steel tubing produced using a welding process. It is shaped into square or rectangular tubes and is made from low-carbon stainless steel (316L), which offers enhanced corrosion resistance due to its higher molybdenum content. It is suitable for applications requiring a combination of strength, appearance, or corrosion resistance, such as structural components, railings, and exhaust systems.



​​ASTM A554 is the standard specification for stainless steel mechanical tubing.​​ ​​ASTM A554 TP316L welded mechanical tubing​​ is produced by ​​flattening the steel and employing automated welding processes without the use of filler materials​​. Among this grade, the ​​ASTM A554 TP316L stainless steel round tube​​ is the most common shape. The ​​A554 TP316L SS square tube​​ is manufactured with a ​​square cross-sectional area​​.

These tubes are designed with ​​sizes up to 16 inches in diameter and wall thicknesses exceeding 0.51 mm​​. The ​​TP316L tubes in this series​​ can be ​​cut, beveled, and threaded​​ as needed. Before leaving the factory, ASME ​​SA554 TP316L stainless steel welded tubes​​ undergo ​​various chemical requirements and testing procedures​​, ensuring their suitability for ​​high-temperature and high-pressure applications​​.For more information or pricing regarding ​​TP316L A554 tubes​​, please feel free to contact us. Email: info@gneestainless.com





ASTM A554 TP316  steel pipe specifications

Specification	:	ASTM A554 TP316/ ASME SA554 TP316
Grades	:	ASTM A554 ( MT304/316, MT316/316L ), JIS G3446 ( SUS316TK, SUS316TK ), CNS 5802 ( 316TK, 316TK ), (YC1)
Size	:	6 NB to 1200 NB IN
Wall Thickness	:	0.6 ~ 3.05 mm
Outer Diameter Size	:	9.5 mm ~ 139.7 mm
Schedule	:	SCH. 5, 10, 60, 20, 30, 40, 80, 100, 120, 140, 160, XXS.
Finish	:	2B Mill Finish , No.4 finish, BA Finish, 400 Grit Finish, 550 Grit Finish, 600 Grit Finish
Method	:	TIG or TIG + Plasma or Laser
Length	:	Single Random, Double Random & Cut Length
Types	:	Square, Rectangle, Round, Coil, "U" Shape, Hydraulic & Honed Tubes



ASTM A554 316L welded square tubing Chemical Composition

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	N
ASTM A554 316L	min.	–	–	–	–	–	16	2.0-3.0	10	–
	max.	0.035	2	0.75	0.045	0.03	18		14	–



ASTM A554 316L welded rectangular tubing Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
				Rockwell B (HR B) max	Brinell (HB) max
ASTM A554 316L	485	170	40	95	217



ASTM A554 316L welded  tubing Physical Properties

Grade	Density (kg/m3)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (m/m/0C)			Thermal Conductivity (W/m.K)		Specific Heat 0-1000C (J/kg.K)	Electrical Resistivity (n.m)
			0-1000C	0-3150C	0-5380C	at 1000C	at 5000C
ASTM A554 316L	8000	193	15.9	16.2	17.5	16.3	21.5	500	740



SS316L Equivalent Grade

TANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
SS 316L	1.4404 / 1.4435	S31603	SUS 316L	316LS11 / 316LS13	03Ch17N14M3 / 03Ch17N14M2	Z3CND17‐11‐02 / Z3CND18‐14‐03	X2CrNiMo17-12-2 / X2CrNiMo18-14-3



Application :

Paper & Pulp Companies

High Pressure Applications

Oil and Gas Industry

Chemical Refinery

Pipeline

High Temperature Application

Water Pipe Line

Nuclear Power Plants

Food Processing and Dairy Industries

Boiler & Heat Exchangers

Stainless steel tube for Chemical and petrochemical



If you have project requirements for ASTM A554 TP316 Steel Pipe, please feel free to place an order. GNEE has a large inventory of popular products for you to choose from. Available in both seamless and welded configurations, contact our factory for detailed chemical composition and free samples. We offer competitive pricing and excellent service.
Packaged in waterproof paper and steel strapping, these products meet standard export seaworthy packaging requirements and can be customized to suit various shipping methods.
