ASTM A213 Stainless Steel 316ti Seamless Tube
Leave a message
Similar to many 300 series austenitic stainless steel, the chemistry of grade 316 could be manipulated to suit the requirements of any application. In this case, industries that benefit using titanium stabilized Stainless Steel 316ti Tube include marine environments, architecture, pulp and paper industry. But in particular, the demand for this particular alloy is noted in industries that use heat exchangers. ASTM A213 specified SS 316ti Tubing could be processed either through hot finishing or cold finishing, in a seamless construction. Since grade 316Ti is an austenitic alloy, the ASTM A213 specifies furnishing via heat treatment. Or substitutional, the ASTM A213 TP316ti tube is to be quenched in water or cooled using any other method, after a hot forming process.
However, the tube must be quenched in such a manner that the temperature of the SS 316ti Heat exchanger Tube is not lower to the minimum temperature of the solution. This specification calls for each component to be subjected to the following tests - Tension test, hardness test, flaring test, flattening test as well as the non-destructive electric test or a hydrostatic test. The heat treatment, together with the addition of about 0.5% titanium in the alloy of Stainless Steel 316ti Seamless Tube improves the ability of the component to withstand elevated temperatures. The stabilizing effect of titanium in SS 316ti Welded Tube also extends to a marked reduction the sensitization, thus reducing the risk of corrosion.
316ti Stainless Steel Seamless Tube Specification
| Stainless Steel 316ti Tube International Specification | ASTM A213, ASTM A269, ASTM A249, ASME SA 213, ASME SA 269, ASME SA 249, EN 10216-5 TC1 / TC2, PED 97/23/EC, AD 2000, NACE MR0175/ISO 15156 |
| Standard Specification of Stainless Steel 316ti Tubing | ASTM, DIN, GB, DS, NF, SAE, TOCT, AISI, EN, JIS, AMS, ASME, DTD |
| 316ti Stainless Steel Tube Standard Tolerances | +/- 0.030; tolerance may vary depending on grade and thickness |
| Stainless Steel 316ti Seamless Tube Size |
15 NB to 150 NB IN 1/2" OD - 12" OD |
| 316ti Stainless Steel Welded Tube Size |
1/2" OD - 12" OD Guage: 25 SWG - 10 SWG |
| Stainless Steel AISI 316Ti Tube Length | Upto 30 meters, Single Random, Double Random & Required Length End: Plain End, Beveled End, Treaded, or Custom Cut Lengths |
| Stainless Steel 316ti 1.4571 Tube WT | 0.40 mm - 12.70 mm |
| Stainless Steel Grade 316ti Tube Schedule | 5, 10S, 10, 30, 40S, 40, 80, 80S, XS, 160, XXH |
| UNS S31635 Stainless Steel Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| WERKSTOFF NR. 1.4571 Stainless Steel Tubes manufacturing techniques | DOM, EFW, ERW, Seamless, CDW, Seam-Welded, CEW, Welded, LSAW, Redrawn, Fabricated |
| Origin of Stainless Steel Type 316ti Tube material | Indian, European, Korean, Japanese |
| AISI 316Ti Stainless Steel Tube End Types |
POE / BOE = Plain One End / Bevelled One End BE : Bevelled end BLE : Bevel large end BBE : Bevel both ends PBE = Plain Both Ends TOE / POE = Treaded One End / Plain One End TBE = Treaded Both Ends TOE / BOE = Treaded One End / Bevelled One End BSE : Bevel small end |
| Stainless Steel 316ti 1.4571 Tube End Finish | low-burr, burr-free, brushed, trovalised |
| WERKSTOFF NR. 1.4571 Stainless Steel Tubes Form | Round, Square, Oval, Rectangular, Coil, "U" Shape, Hydraulic & Honed Tubes |
| ASTM A213 TP316ti Tube Delivery Condition |
Welded, calibrated Welded and redrawn Seamlessly drawn Polished Annealed and Pickled Hot Finished Bright Annealed Cold Drawn |
| 316ti Grade Stainless Steel Tube Packing |
Ply Wooden Boxes PE Fabric Bundles Steel Strips Bundled Standard seaworthy export packing Plastic Bags, or as required |
| ASME SA 213 TP 316Ti Tube Value Added Services | Cut to size, thread, and groove |
| Port | Mumbai, India |
| Stocking distributor of leading Stainless Steel 316ti Tube manufacturers |
Sanyo Special Steel, Japan make Stainless Steel 316ti Tube Schoeller Bleckmann, Austria make 316ti Stainless Steel Seamless Tube Nippon Steel Corporation, Japan make Stainless Steel Grade 316ti Tube Sumitomo Metals, Japan make UNS S31635 Stainless Steel Tubes Seah Steel Corporation, Korea make Stainless Steel 316ti 1.4571 Seamless Tube Kobe Special Tube, Japan make WERKSTOFF NR. 1.4571 Stainless Steel Tubing Tubacex Tubos Inoxidables S.A., Spain make Stainless Steel Type 316ti Tubes |
| ASME SA 213 TP 316Ti Tube Dimensional Specification | ANSI/ ASME B36.10, B36.19, B2.1 |
| Marking on 316ti Type Stainless Steel Tube |
Specification Material Grade Nominal Size Schedule or Wall Thickness Method of Manufacturing (Seamless or Welded) Heat Number Manufacturer's Name or Custom Logo - on request Marked Tube Sample: ASME SA 213 TP316ti 12" NB SCH 40S SEAMLESS HEAT NO. XXXX |
| Application wise types of Stainless Steel Type 316ti Tubes | AISI 316Ti Stainless Steel Oil Tube, Gas Tube, Fluid Tube, Boiler and Stainless Steel AISI 316Ti Heat exchanger Tube |
| Uses | Boiler, Heat Exchanger, Super Heaters and Reheaters |
316ti Grade Stainless Steel Welded Tube Tolerances
Straightness: .030" in 3"
Wall Tolerance +/- 10%
| O.D. INCHES | WALL THICKNESS INCHES | O.D. +/- INCHES |
|---|---|---|
| 1/2" to 1" incl. | .025 to .065 | .005 |
| Over .065 to .134 | .010 | |
| 1 to 1-1/2" incl. | .025 to .065 | .008 |
| Over .065 to .134 | .010 | |
| 1-1/2" to 2" incl. | .025 to .049 | .010 |
| Over .049 to .083 | .011 | |
| Over .083 to .148 | .012 | |
| 2" to 2-1/2" incl. | .032 to .065 | .012 |
| Over .065 to .109 | .013 | |
| Over .109 to .165 | .014 | |
| 2-1/2" to 3-1/2" incl. | .032 to .165 | .014 |
| Over .165 to .220 | .020 | |
| 3-1/2" to 5" incl. | .083 to .165 | .020 |
| Over .165 to .220 | .025 |
316ti Type Stainless Steel Seamless Tube Chemical Properties
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 316TI | min. | - | - | - | - | - | 16.0 | 2.0-3.0 | 10.0 | - |
| max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0 | 14.0 | 0.1 | ||
Austenitic Stainless Steel 316ti Tube Mechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 316TI | 515 | 205 | 35 | 75 | 205 |
SS 316ti Tube Equivalents
| ALLOY | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316TI | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
If you have project requirements for 316Ti 1.4571 stainless steel bars, we welcome your order. GNEE has a large inventory of popular products for you to choose from. It can be processed into various practical product forms, including plates, coils, tubes, bars, and wires. For detailed chemical composition and free samples, please contact our factory immediately. We offer competitive prices and excellent service.Email: info@gneestainless.com
