ASTM A564 Type 630 H1100 Stainless Steel bar
Leave a message
What is A564 type 630 material?
ASTM A564 is a standard material specification for hot-rolled and cold-finished age-hardening stainless steel bars, including type 630 / UNS S17400 / 17-4 PH used for parts requiring corrosion resistance and high strength at room temperature, or at temperatures up to 600°F [315°C].
What is H1100 material?
Stainless Steel 17-4 H1100 is a precipitation-hardening martensitic Stainless Steel, which has corrosion resistance comparable to austenitic varieties. Our H1100 has been heat-treated to a minimum tensile strength of 140ksi, yield strength of 115ksi, an elongation in 2in of 14%, and a reduction of area of 45%.
What is the difference between H900 and H1100?
The H900 condition using solution annealing, rapid quenching, and aging generates a predominantly martensitic microstructure that maximizes strength and hardness. H1100 treatment creates some ferrite fraction by slightly slower cooling, enhancing toughness.
ASTM A564 TYPE 630 UNS S17400 17-4PH Round Bar Specification
Form: Round, Square, Hex (A/F), Bush, Rectangle, Flat, Billet, Ingot, Forging, PSQ Bar, Wire Rod, Wire (Coil Form), Wire-mesh etc.
Size Range: 15NB to 150NB
Length: 100 mm To 3000 mm Long & Above
Diameter (Size) : Metric M6 to M48, Inches - 1/4'' to 2''
Tolerance : H8, H9, H10, H11, H12, H13, K9, K10, K11, K12 or as per clients' requirements
Finish : Cold Drawn, Shot Blast & Drawn, 240 Grit Belt Polished, Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish, High Polished
Condition : Cold Drawnd Polished Cold Drawn Centreless Ground & Polished, Threading
Surface : Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline
compositional ranges of grade 630 stainless steels
| Grade | C | Mn | Si | P | S | Cr | Ni | Cu | Nb+Ta | |
| 630 |
min. max |
- 0.07 |
- 1 |
- 1 |
- 0.04 |
- 0.030 |
15 17.5 |
3 5 |
3 5 |
0.15 0.45 |
Mechanical properties of grade 630 stainless steels
| dition | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (% in 50mm) | Hardness | |
| Rockwell C (HR C) | Brinell (HB) | ||||
| Solution Treated | 1105 typ | 1000 typ | 15 typ | 38 max | 363 max |
| Condition 900 | 1310 min | 1170 min | 10 min | 40 min | 388 min |
| Condition 1150 | 930 min | 724 min | 16 min | 28 min | 277 min |
physical properties of grade 630 stainless steels
| Mean Co-eff of Thermal Expansion (µm/m/°C) | Thermal Conductivity (W/m.K) |
Specific Heat 0-100°C (J/kg.K) |
Elec Resistivity (nΩ.m) |
||||||
| 0-100°C | 0-315°C | 0-538°C | At 100°C | At 500°C | |||||
| 630 | 7750 | 197 | 10.8 | 11.6 | - | 18.4 | 22.7 | 460 | 800 |
Latest Price List for ASTM A564 TYPE 630 Round Bars
ASTM A564 GRADE 630, ASTM A564 630, ASTM A564 UNS S17400, ASTM A564 GR 630 17-4PH
17-4ph Stainless Steel Bar UNS S17400 SUS630 W.Nr 1.4542
FOB Price: US$0.5-1/kg
17-4PH Type 630 Steel Round Bar conforming to ASTM A564 standard
FOB Price: US$5000-6500/ton
ASTM Type 630 17-4 ph Stainless Steel Round Bar for Chemical Equipment
FOB Price: US$2-3/kg
17-4PH (UNS S17400, Type 630) Stainless Steel Bar/Rod
FOB Price: US$0.5-1/kg
GNEE supplies 17-4PH stainless steel bars, including: ASTM A564 TP630 rectangular bars, which can be easily welded and machined using conventional methods and are supplied in the solution annealed condition. A564 GR 630 hexagonal bars are not recommended for low-temperature applications above 572 degrees Fahrenheit (approximately 300 degrees Celsius). If stains on the ASTM A564 Grade 630 bright bars are difficult to remove, a stiff brush or stainless steel brush can be used for cleaning. We manufacture ASTM A564 GR 630 hollow bars and supply them to various customers in different industries.
