What is the difference between 1.4301 stainless steel and 304? When purchasing stainless steel materials, many people will encounter such questions: Are 1.4301 and 304 stainless steel the same material? Can 1.4301 stainless steel and 304 replace each other? Is there any difference in quality or price?
This article will help purchasers quickly clarify the concepts from the four perspectives of standards, performance, application, and certification to avoid misunderstandings in material selection.
1. 1.4301 stainless steel and 304：Standards
| Name | Standard System | Common Usage Regions |
|---|---|---|
| 1.4301 | EN 10088 (European Standard) | Europe, China (for export to Europe) |
| 304 | AISI/ASTM (American Standard) | North America, international trade in Asia |
Both belong to the 18-8 austenitic stainless steel family, containing approximately 18% chromium and 8% nickel. They are widely used in kitchen equipment, food processing, architectural applications, and medical devices.
2. 1.4301 stainless steel VS.304：Chemical Composition
| Element | 1.4301 (EN) | 304 (AISI) |
|---|---|---|
| Cr (Chromium) | 17.5–19.5% | 18.0–20.0% |
| Ni (Nickel) | 8.0–10.5% | 8.0–10.5% |
| C (Carbon) | ≤0.07% | ≤0.08% |
| Mn, Si, S, P | Trace amounts; controlled within similar limits |
3.1.4301 stainless steel VS.304：Mechanical Properties Comparison
| Property | 1.4301 (EN Standard, Annealed) | 304 (ASTM Standard, Annealed) | Remarks on Differences |
|---|---|---|---|
| Tensile Strength | ≥520 MPa | ≥515 MPa | Slight difference in standard minimums, but actual production typically yields 520–700 MPa for both; difference is negligible. |
| Yield Strength | ≥215 MPa | ≥205 MPa | EN standard for 1.4301 is slightly higher, but after processing (e.g., cold forming, welding), actual values are comparable. |
| Elongation | ≥40% | ≥40% | Identical, indicating excellent ductility and suitability for complex forming and welding. |
| Hardness (HBW) | ≤187 | ≤187 | Same in annealed condition. Cold working may cause minor differences, but not enough to affect interchangeability. |
| Elastic Modulus | ~200 GPa | ~200 GPa | Identical, indicating the same stiffness and structural stability. |
| Poisson's Ratio | 0.28 | 0.28 | Identical, reflecting the same deformation characteristics (ratio of transverse to longitudinal strain). |
| Fatigue Strength | 200–330 MPa | 210–440 MPa | 304 may have a slightly higher upper fatigue limit, but in practical applications, the difference is minimal and condition-dependent. |
For procurement, the key question is: Can 1.4301 stainless steel and 304 be used interchangeably? Will it affect product quality or certification?
1. Interchangeable in conventional engineering and industrial products: As long as the customer specifications or project standards are met, 1.4301 and 304 can be considered equivalent materials.
2. Special projects must be executed according to drawings or certification: For example, if the project exported to Europe requires EN standard certification, 1.4301 should be specified; if it is accepted according to ASTM standards, 304 should be marked.
